Fluido®

Revolução em aquecimento de sangue e fluidos.



Fluido® | tecnologia de infravermelhos.
Fluido® introduz uma nova geração de aquecedores de sangue e fluidos e ®evoluciona a luta contra a hipotermia. Fluido®, é baseado na revolucionaria tecnologia de infravermelhos, um metodo seco, rapido e seguro que permite aquecer sangue e fluidos a temperatura desejada em apenas 30 segundos, mesmo no fim da linha.



Fluido®, o futuro em aquecimento de sangue e fluidos



Intelligent heat
The Fluido® is accurate, reliable and user friendly. It provides “intelligent heat”, through direct flow and temperature measurements in the cassette. The internal software calculates the exact temperature loss in the line and adjusts its heating capacity accordingly.



Fast and easy
The Fluido® is easy to use. As soon as the disposable set is connected and primed, the set temperature has been reached. The Fluido® performs at all flow rates, the set temperature at the end of the line can be guaranteed from 20-800 ml/min.



Fluido® AirGuard System

Aquecimento de sangue e fluidos.



Fluido® utililza tecnología de infravermelhos,  um metodo seguro, seco e fiavel que previne a contaminacão quando comparado a sistemas que utilizam agua. Fluido® atinge rapidamente a temperatura selecionada em apenas 30 segundos, sendo adequado para todas as aplicações. Da anestesia ao traumatismo de alto fluxo.









Fluido® Air Guard
• Detecção de ar, bolhas e espuma
• Bloqueio automatico
• Apto para aplicação cardiaca



Fluido® Camara de Pressão
•  500 ml e 1000 ml
• pressão 0-300 mmHg
• apenas 15 segundos





Fluido®
• Apto para aplicação cardiaca
• Temperatura de 30ºC a 39ºC
• Indicador de fluxo e volume
Fluido® Compressor
• Silencioso
• Potente
• Apto para aplicação cardiaca
Sistemas



671200 | Fluido Standard Set

Fluido Standard Set

  • Rigid cassette
  • De-aeration chamber
  • Manual air relief
  • Backflow valve
  • Patient line: 1500 mm
  • Priming volume: 90 ml

Article number – 671200

Flow rates

  • Max. flow 650 ml/min*
  • Normothermic flow 20 – 400 ml/min*

* Free flow (without catheter attached) with 300 mmHg
Incoming fluid temperature of 20°C and normothermic flow between 36°C and 37,5°C

671500 | Fluido Trauma Set

The Fluido Trauma Set is ideal for flow rates up to 750 ml/min. *

  • Rigid cassette
  • De-aeration chamber with 200 μm filter
  • Manual air relief
  • Backflow valve
  • Y shaped  IV system
  • Administration port
  • Patient line: 150 cm
  • Priming volume: 145 ml

Flow rates

  • Max flow 800 ml/min*
  • Normothermic flow 20 – 750 ml/min*

When to use the Fluido Trauma Set?

  • Trauma procedures
  • Liver transplants
  • Abdominal Aortic Aneurisms (AAA)
  • Cardio surgery

* Free flow (without catheter attached) with 300 mmHg
Incoming fluid temperature of 20°C and normothermic flow between 36°C and 37,5°C

671700 | Fluido Trauma Set Plus

The Fluido Trauma Plus Set is ideal for flow rates up to 650 ml/min. *

  • Rigid cassette
  • De-aeration chamber with 200 μm filter
  • Manual air relief
  • Backflow valve
  • Y shaped  IV system with three spikes
  • Administration port
  • Wider drip chamber and tubing
  • Patient line: 200 cm
  • Priming volume: 145 ml

Flow rates

  • Max flow 1100 ml/min*
  • Normothermic flow 20 – 650 ml/min*

When to use the Fluido Trauma Plus Set?

  • Same applications as Trauma Set
  • When even higher flows are desired: up to 1100 ml/min*
  • Third spike as an addition to speed up handling time
  • With central catheters used
    • Liver transplant
    • Abdominal Aortic Aneurisms (AAA)
    • Cardio surgery

* Free flow (without catheter attached) with 300 mmHg
Incoming fluid temperature of 20°C and normothermic flow between 36°C and 37,5°C
